Minimum Order Quantity: 2 pieces
가격: CN¥33,523.69/pieces >=2 pieces
private mold: |
NO |
products status: |
Stock |
type: |
Rack |
processor main frequency: |
2.8GHz |
processor type: |
Intel xeon |
brand name: |
Le-novo |
model number: |
SR950V3 |
place of origin: |
Beijing, China |
Model NO.: |
SR950V3 |
Form Factor: |
8U rack server |
Processor: |
8x 4th Gen Intel Xeon Scalable Processors "Sapphire Rapids" |
Memory: |
Up to 32TB |
Internal storage: |
16x 2.5-inch |
RAID: |
SAS/SATA RAID adapters with up to 4GB flash |
Networking: |
Optional OCP slot with PCIe Gen4 x16 interface for 1Gb, 10Gb or |
PCIe: |
Supports PCIe 5.0 |
Management and security: |
Integrated XClarity Controller 2 |
Power: |
1800W AC hot-swap power supplies |
private mold: |
NO |
products status: |
Stock |
type: |
Rack |
processor main frequency: |
2.8GHz |
processor type: |
Intel xeon |
brand name: |
Le-novo |
model number: |
SR950V3 |
place of origin: |
Beijing, China |
Model NO.: |
SR950V3 |
Form Factor: |
8U rack server |
Processor: |
8x 4th Gen Intel Xeon Scalable Processors "Sapphire Rapids" |
Memory: |
Up to 32TB |
Internal storage: |
16x 2.5-inch |
RAID: |
SAS/SATA RAID adapters with up to 4GB flash |
Networking: |
Optional OCP slot with PCIe Gen4 x16 interface for 1Gb, 10Gb or |
PCIe: |
Supports PCIe 5.0 |
Management and security: |
Integrated XClarity Controller 2 |
Power: |
1800W AC hot-swap power supplies |
Components | Specification |
Machine types | 7DC4 - 3-year warranty 7DC5 - 1-year warranty 7DC6 - SAP HANA configurations with 3-year warranty |
Form factor | 8U rack (two 4U chassis that are cabled together) |
Processor | 8x 4th Gen Intel Xeon Scalable Platinum processors (formerly codename "Sapphire Rapids" or SPR). Supports processors up to 60 cores, core speeds up to 2.9 GHz, and TDP ratings up to 350W. Four Intel Ultra Path Interconnect (UPI) links at 16 GT/s each. Eight processors are connected in a mesh topology. Support for up to four Intel embedded accelerators: QAT, DLB, IAA, and DSA. |
Chipset | Intel C741 "Emmitsburg" chipset, part of the platform codenamed "Eagle Stream" (EGS) |
Memory | Up to 128 DIMM slots (16 DIMMs per processor). Each processor has 8 memory channels, with 2 DIMMs per channel. Lenovo TruDDR5 RDIMMs and 3DS RDIMMs are supported. DIMMs operate at up to 4800 MHz at 1 DPC and 4400 MHz at 2 DPC. |
Memory maximums | Up to 32TB with 128x 256GB 3DS RDIMMs and eight processors (4.0TB per processor). |
Memory protection | ECC, SDDC (for x4-based memory DIMMs), ADDDC (for x4-based memory DIMMs), memory mirroring. |
Disk drive bays | Up to 16x hot-swap drive bays: * Up to 16x 2.5-inch SAS/SATA drive bays * Up to 16x E3.S EDSFF PCIe 5.0 NVMe drive bays Support for two M.2 NVMe drives using an M.2 adapter with integrated Marvell 88NR2241 NVMe RAID controller |
Maximum internal storage | * 2.5-inch drives: * 491.52TB using 16x 30.72TB 2.5-inch SAS/SATA SSDs * EDSFF drives * 245.76TB using 16x 15.36TB EDSFF PCIe 5.0 NVMe SSDs |
Storage controller | * Up to 16x Onboard PCIe 5.0 NVMe ports (RAID functions provided using Intel VROC) * 12 Gb SAS/SATA RAID adapters * 12 Gb SAS/SATA HBA (non-RAID) |
Network interfaces | One dedicated OCP 3.0 SFF slot with PCIe 4.0 x16 host interface. Supports network adapters up to 25 GbE. One port can optionally be shared with the XClarity Controller (XCC) management processor for Wake-on-LAN and NC-SI support. |
PCI Expansion slots | Up to 14 PCIe slots, plus one OCP 3.0 Gen4 slot. Slot are located on the primary and secondary chassis system boards. * 6x Front FHHL PCIe 5.0 x16 slots * Up to 8x Rear FHHL PCIe 4.0 x16 slots See the I/O expansion options section for details. |
Ports | Front: One VGA video port. 2x USB 3.2 G1 (5 Gb/s) port, 1x USB 2.0 port, one VGA video port, one DB-9 serial port, and one RJ-45 XClarity Controller (XCC) systems management port. The serial port can be shared with the XCC for serial redirection functions. The USB 2.0 port can be configured to support local systems management by using the XClarity Administrator mobile app on a mobile device connected via a USB cable. Rear: No ports Internal: Onboard dedicated slots for M.2 drives (for OS boot support, including hypervisor support). 1x USB 3.1 (5 Gb/s) port. |
Cooling | 24x simple-swap dual-rotor 60 mm fans (all standard). 12 fans installed in each 4U chassis, and are N+2 rotor redundant (which means that the server can tolerate two rotor failures in each of the two 4U chassis and continue full operation). One additional fan integrated in each of the power supplies. |
Power supply | 8x or 12x hot-swap redundant 1800W AC power supplies, depending on the configuration, with 4x or 6x installed in each chassis. Power supplies are 80 PLUS Titanium certified. Power supplies require 220V power (110V not supported). Power supplies are N+N redundant within each chassis. |
Dimensions | Width: 443 mm (17.4 in.), height: 175 mm (6.9 in.), depth: 973 mm (38.3 in.). |
Weight | 50 kg (110.23 lb) maximum per 4U chassis (100 kg total) |
